APC AP6020A power distribution unit (PDU) 13 AC outlet(s) 0U/1U Black

Name: APC AP6020A power distribution unit (PDU) 13 AC outlet(s) 0U/1U Black
SKU: AP6020A
Price: 117.059101 EUR
Availability: InStock

Additional Information

Details

Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (13) C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.

Full Specification

SKU

AP6020A

EAN

0731304327806

Specification

Design
Type	Single-phase
PDU types	Basic
Mounting	Horizontal/Vertical
Product colour	Black
Certification	cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH
Rack capacity	0U/1U
Ports & interfaces
AC outlets quantity	13 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C20 coupler
Output connections	IEC 320 C13
Features
Certification	cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH
Power
Maximum power	3680 W
Nominal input voltage	100-240 V
Maximum current	20 A
Maximum total current draw per phase	16 A
Maximum input current per phase	16 A
Load capacity	3680 VA
AC input frequency	50 - 60 Hz
Certificates
Certification	cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-15 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Weight & dimensions
Weight	1.5 kg
Width	44 mm
Depth	93 mm
Height	388 mm
Package width	210 mm
Package depth	76 mm
Package height	436 mm
Package weight	2.02 kg
Packaging data
Package width	210 mm
Package depth	76 mm
Package height	436 mm
Package weight	2.02 kg
Technical details
Total carbon footprint (kg of CO2e)	38.04
Compliance certificates	RoHS
Logistics data
Total carbon footprint (kg of CO2e)	38.04

Manufacturer

APC

Short Description

NetShelter Basic Rack PDU, 0U, 1PH, 3.3kW, 100-240V 20A or 200-240V 16A, 13 C13 outlets, C20 inlet

Description

Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (13) C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
