This APC Smart-UPS is designed for small to medium business users to maintain business uptime and continuity. This 1000VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. The UPS comes with IEC 320 C14 input, 4x IEC 320 C13 outlets, and 2x IEC jumper cables. This UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS C has an intuitive graphic LCD interface. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. This line interactive UPS operates in green mode for high operating efficiency. The SMC has a 2-year warranty, and comes with a built-in lead-acid battery. This UPS provides surge protection against lightning strikes, power sags, brownouts and surges. This is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. Designed for small offices or small business owners to maintain a core network and business communication.
Alarm when on battery, Low battery alarm, Overload alarm
UPS topology
Line-Interactive
Waveform
Sine
Automatic Voltage Regulation (AVR)
Yes
Surge protection
Yes
Noise level
41 dB
Audible alarm(s)
Yes
Features
Output frequency
50/60 Hz
Audible alarm modes
Alarm when on battery, Low battery alarm, Overload alarm
UPS topology
Line-Interactive
Waveform
Sine
Automatic Voltage Regulation (AVR)
Yes
Output power
600 W
Input operation voltage (min)
170 V
Input operation voltage (max)
300 V
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Surge energy rating
680 J
Surge protection
Yes
Output voltage Total Harmonic Distortion (THD)
5%
Noise level
41 dB
Audible alarm(s)
Yes
Output power capacity
1 kVA
Input frequency
50/60 Hz
Battery
Battery life (max)
6 year(s)
Number of batteries supported
1
Battery technology
Sealed Lead Acid (VRLA)
Battery recharge time
3 h
Replacement battery cartridge
APCRBC124
Design
Rack capacity
2U
Form factor
Rackmount
Product colour
Black
Certification
CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH
Cable length
2.44 m
Display type
LCD
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 15000 m
Technical details
Output frequency
50/60 Hz
Sustainability certificates
ENERGY STAR
Harmonized System (HS) code
85078000
Total carbon footprint (kg of CO2e)
945.86
Compliance certificates
RoHS
Certificates
Certification
CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH
Compliance certificates
RoHS
Packaging content
Cables included
RJ-45, RS-232
Rack mount kit
Yes
Management card included
No
Resource CD
Yes
Software CD
Yes
Sustainability
Sustainability certificates
ENERGY STAR
Weight & dimensions
Package width
535 mm
Package depth
570 mm
Package height
235 mm
Weight
20.5 kg
Width
432 mm
Package weight
20.7 kg
Height
86 mm
Depth
406 mm
Packaging data
Cables included
RJ-45, RS-232
Resource CD
Yes
Rack mount kit
Yes
Software CD
Yes
Package width
535 mm
Package depth
570 mm
Package height
235 mm
Package weight
20.7 kg
Management card included
No
Logistics data
Products per pallet
16 pc(s)
Harmonized System (HS) code
85078000
Total carbon footprint (kg of CO2e)
945.86
Manufacturer
APC
Short Description
Smart-UPS C, Line Interactive, 1000VA, Rackmount 2U, 230V, 4x IEC C13 outlets, SmartConnect port, USB and Serial communication, AVR, Graphic LCD
Description
This APC Smart-UPS is designed for small to medium business users to maintain business uptime and continuity. This 1000VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. The UPS comes with IEC 320 C14 input, 4x IEC 320 C13 outlets, and 2x IEC jumper cables. This UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS C has an intuitive graphic LCD interface. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. This line interactive UPS operates in green mode for high operating efficiency. The SMC has a 2-year warranty, and comes with a built-in lead-acid battery. This UPS provides surge protection against lightning strikes, power sags, brownouts and surges. This is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. Designed for small offices or small business owners to maintain a core network and business communication.
